• Shipping Weight: 0.1kgs
  • 0 Units in Stock

  Designed to allow quick and easy connection for the gas input and beer output on your Cornelius keg.

These are CMB brand which are made in Germany.  These disconnects have a plastic pin.

I also sell genuine Cornelius brand disconnects which have a stainless steel pin in them (see other listing).

The disconnects are attached to the posts by withdrawing the collar which releases 4 ball bearings on the inner diameter, its then pushed onto the post, and the collar released locating the balls into a machined groove. A plunger in the disconnect depresses a poppet valve built into the post allowing the flow of gas or liquid. When the disconnect is removed a spring automatically closes the poppet valve preventing the loss of any pressure or liquid. It also prevents the ingress of any O2 protecting the contents from oxidation. The grey (gas) disconnect will not fit the OUT post and the black (liquid) disconnect will not fit the IN post.

Features :

  • 1 x Black Disconnect for liquid
  • 1 x Grey Disconnect for gas
  • 6mm barb (will fit 5mm hose once softened with hot water)
  • Food grade plastic construction
  • Made in Germany by CMB brand
  • Height: 6cm

Ask a question

Sold Out
